MDT SCN-GLED1W.01 KNX sklenený LED displej, biely

The MDT SCN-GLED1W.01 is a KNX glass LED indicator that provides clear visual status signaling for building automation systems. Its white LED is configurable in brightness and supports blinking and night mode for flexible indication.

Advantages

The white glass panel blends elegantly into modern interiors while the LED offers adjustable brightness and blinking function. Integrated bus coupler and ETS configuration ensure seamless KNX integration.

Suitable for

• Status indication in KNX smart homes and buildings
• Visual alerts for doorbell, alarm, or presence detection
• Flush-mounted installation in standard switch boxes

Key specifications

• Number of LEDs: 1
• LED color: White (configurable brightness)
• Panel material: Glass
• Panel color: White
• Power supply: KNX bus, max. 5 mA
• Installation: Flush-mounted
• Configuration: ETS
• Protection class: IP20
• Operating temperature: 0 to +45 °C
• Visible dimensions: 92 x 92 x 11 mm
• Installation depth: approx. 20 mm

Recommendations

For reliable KNX status indication with a sleek glass design, the MDT SCN-GLED1W.01 is an excellent choice.
