MEAN WELL APV-25-24 LED driver konštantného napätia 24V 25W IP42 biely

LED installations often fail prematurely when powered by unstable or poorly matched drivers. The MEAN WELL APV-25-24 eliminates that risk by delivering a rock-steady 24 VDC output for low-power LED strips, modules, and signage. This compact, fanless unit operates silently and reliably across a wide temperature range, making it a dependable backbone for both indoor and sheltered outdoor lighting projects.

Who is it for

This driver is ideal for electricians, lighting contractors, and DIY enthusiasts who need a safe, constant-voltage power source for 24 V LED systems up to 25 W. It suits residential under-cabinet lighting, retail display illumination, architectural accent lighting, and any project where space is limited and silent operation is required.

Main features

• Constant voltage output: stable 24 VDC, 1.04 A, 25 W
• Wide AC input range: 90–264 VAC, 47–63 Hz
• High efficiency up to 83% for lower energy costs
• Comprehensive protections: short circuit, overload, over voltage
• IP42-rated plastic housing resists dust and dripping water
• Class II double insulation – no earth connection needed
• Passive cooling by free air convection – completely silent
• Compact and lightweight for easy installation in tight spaces
• Complies with UL1310 Class 2 and EN61347 safety standards

Specifications

• Brand: MEAN WELL
• Model: APV-25-24
• MPN: APV-25-24
• EAN: 4021087026659
• Output voltage: 24 VDC
• Output current: 1.04 A
• Output power: 25 W
• Input voltage: 90–264 VAC
• Input frequency: 47–63 Hz
• Efficiency: 83%
• Protections: short circuit, overload, over voltage
• Operating temperature: -30 °C to +70 °C
• Storage temperature: -40 °C to +80 °C
• IP rating: IP42
• Electrical class: Class II
• Cooling: free air convection (fanless)
• Housing material: plastic
• Colour: white
• Safety standards: UL1310 Class 2, EN61347-1, EN61347-2-13
• Power factor correction: No
• Dimming function: No

Tips

Always verify that your LED load does not exceed 25 W and matches the 24 V constant voltage requirement. For outdoor use, ensure the driver is mounted in a location protected from direct rain, as IP42 is not suitable for heavy water exposure. Leave at least 10 cm of clearance around the unit for proper heat dissipation.
