MEAN WELL MDR-60-5 DIN-lištový napájací zdroj 5V 10A 50W

In industrial control cabinets and building automation panels, the MEAN WELL MDR-60-5 provides stable 5V DC power for sensors, controllers, and other sensitive electronics. Its compact DIN rail mount design saves space while delivering reliable performance in demanding environments.

Key specifications

• Output: 5V DC, 10A, 50W
• Input: 85-264VAC or 120-370VDC
• Efficiency: 80%
• Mounting: DIN rail TS-35/7.5 or 15
• Protections: short circuit, overload, over voltage
• Operating temperature: -20 to +70°C
• Ripple & noise: 80mVp-p
• Voltage adjustment: 4.75-5.5V DC
• Isolation: 3kVAC input-output
• Certifications: UL508, TUV EN60950-1, CE
• Cooling: free air convection
• No load power consumption: <1W
• MTBF: >500,000 hours
• Housing: plastic

Why choose it

The MDR-60-5 is built for reliability with a slim 40mm width, high efficiency, and robust protections. Its wide input range and adjustable output make it versatile for various installations, while the DIN rail clip ensures quick and secure mounting.

Ideal use cases

• Industrial automation systems
• Building management and HVAC controls
• Security and access control panels
• Test and measurement equipment
• LED lighting control circuits

Good to know

The unit operates with free air convection, eliminating fan noise and maintenance. It meets international safety standards, ensuring compliance in global projects. The plastic housing is lightweight yet durable, suitable for indoor electrical enclosures.
