MENNEKES Cepex nástenná zásuvka 32A 5P 6H 400V IP44 červená 4170

Industrial electricians and facility managers install the MENNEKES Cepex wall-mounted socket in workshops, production halls and outdoor areas where a robust 32 A three-phase connection is needed. The red housing signals the 400 V, 6h earth position configuration at a glance, while the IP44 rating protects against splashing water and solid objects over 1 mm.

Key specifications

• Rated current: 32 A
• Rated voltage: 400 V (380–415 V)
• Poles: 5 (3P+N+PE)
• Earth contact position: 6h
• Ingress protection: IP44
• Frequency: 50/60 Hz
• Connection: screw terminals
• Housing material: polyamide (PA6)
• Mounting: surface-mounted
• Colour: red
• Cable entry: via cable gland
• Operating temperature: -25 °C to +40 °C
• Impact resistance: IK08
• Standard: IEC 60309-1, IEC 60309-2

Why choose it

The Cepex series combines a tough polyamide housing with screw terminals that stay secure under vibration. The 6h earth position prevents mismating with other voltage systems, and the IP44 rating suits semi-protected outdoor locations.

Ideal use cases

• Powering portable machinery in workshops
• Outdoor construction site distribution boards
• Agricultural buildings with three-phase equipment
• Marinas and campsites with 400 V supply points

Good to know

The socket is surface-mounted and accepts cable entry through a gland, allowing flexible installation on walls or panels. It is designed for 50/60 Hz networks and carries the CE mark.
