METZ CONNECT 110666 Výkonové relé biele DPDT 24V DC 8A montáž na PCB

The METZ CONNECT 110666 power relay stands out with its robust DPDT contact configuration and high switching capacity, making it a reliable choice for demanding industrial control applications. Unlike standard relays, it offers a compact PCB-mount design with flux-proof protection, ensuring stable performance even in challenging environments.

Highlights

• DPDT (2 changeover) contacts for versatile switching
• 8 A rated current at 250 V AC
• 24 V DC coil with low power consumption (0.53 W)
• High insulation voltage: 5000 V AC between coil and contacts
• Flux-proof (RT II) for protection against soldering fluxes
• Wide operating temperature range: -40 to +70 °C

In daily use

This relay excels in automation, HVAC, and power distribution systems where dependable switching is critical. Its silver nickel contacts ensure long electrical life, while the through-hole PCB mounting simplifies integration into existing designs. The white housing provides clear visual identification in dense circuit boards.

Full specifications

• Contact configuration: DPDT (2 changeover)
• Coil voltage: 24 V DC
• Rated contact current: 8 A (AC1)
• Rated contact voltage: 250 V AC
• Max. switching power: 2000 VA (AC1), 240 W (DC1)
• Contact material: AgNi (Silver Nickel)
• Number of pins: 8
• Mounting: PCB through-hole
• Insulation voltage (coil/contact): 5000 V AC
• Dielectric strength (open contacts): 1000 V AC
• Operating temperature: -40 to +70 °C
• Protection class: RT II (flux proof)
• Coil power consumption: 0.53 W
• Electrical life: 100,000 operations (resistive load)
• Mechanical life: 10,000,000 operations
• Colour: White

Final note

With its high insulation and robust construction, the METZ CONNECT 110666 is a dependable component for professionals seeking long-term reliability in switching applications.
