METZ CONNECT rozvádzač 19 palcov, 1HE, 56 mm, RAL 9005 čierna (130894-01-29-E)

The METZ CONNECT 130894-01-29-E is a high-performance Cat.6A keystone module designed for reliable data transmission in structured cabling systems. This unshielded (UTP) RJ45 jack features a 180° straight connection angle and supports Power over Ethernet (PoE, PoE+, 4PPoE) for versatile network applications. The robust plastic housing in black ensures durability and easy identification.

Advantages

This keystone module offers tool-free or LSA termination for quick and secure installation. It is backward compatible with Cat.6 and Cat.5e systems, providing future-proof performance. The gold-plated contacts guarantee excellent conductivity and corrosion resistance, ensuring long-term reliability.

Suitable for

• Data centers and server rooms requiring high-speed connectivity
• Enterprise networks with PoE devices such as IP cameras, access points, and VoIP phones
• Structured cabling in patch panels and wall outlets
• Industrial environments where robust and reliable connections are essential

Key specifications

• Module Type: Keystone Module
• Connector Type: RJ45 Jack
• Performance Category: Cat.6A (Class EA)
• Shielding: Unshielded (UTP)
• Connection Angle: 180° (Straight)
• Termination Type: IDC / LSA, Tool-free
• Housing Material: Plastic
• Color: Black
• Mounting Standard: Keystone Format
• Contact Plating: Gold-plated
• Wire Gauge (Solid): AWG 24/1 - AWG 22/1
• Wire Gauge (Stranded): AWG 26/7 - AWG 22/7
• PoE Support: PoE, PoE+, 4PPoE (IEEE 802.3af/at/bt)
• Number of Contacts: 8P8C
• Standards Compliance: ISO/IEC 11801, EN 50173, TIA/EIA-568-C.2
• Operating Temperature: -10°C to +60°C
• Storage Temperature: -40°C to +70°C
• Transmission Bandwidth: Up to 500 MHz

Recommendations

For optimal performance, use with Cat.6A or higher cabling and ensure proper termination. This module is ideal for high-bandwidth applications such as 10GBASE-T and PoE++ deployments.
