MIBOXER D5-CX LED DMX 5-kanálový ovládač séria DMX

The MIBOXER D5-CX is a professional 5-channel LED DMX controller designed for versatile lighting control in commercial and residential applications. It supports multiple LED types including RGB+CCT, RGBW, RGB, Dual White, and Single Color, making it an ideal solution for dynamic lighting setups.

Advantages

With DMX512 protocol compatibility, this controller offers precise and reliable control over your LED lighting. The digital display and manual buttons allow easy DMX address setting, while the screw terminals and RJ45 connections ensure secure and straightforward installation. Overload and short circuit protection guarantee safe operation.

Suitable for

• Stage and architectural lighting
• Retail and hospitality environments
• Home automation and smart lighting systems
• Event and exhibition lighting

Key specifications

• Control Protocol: DMX512
• Number of Channels: 5
• Supported LED Types: RGB+CCT, RGBW, RGB, Dual White, Single Color
• Input Voltage: DC12-24V
• Output Current: 3A per channel (Max 15A total)
• Max Output Power: 180W (12V) / 360W (24V)
• Output Type: Constant Voltage
• Dimming Range: 0-100%
• DMX Address Setting: Manual via buttons/digital display
• DMX Channels Used: 5
• Connection Interface: Screw terminals (Power In/Out), RJ45 (DMX In/Out)
• Operating Temperature: -20°C to 60°C
• Protection Features: Overload protection, Short circuit protection
• Static Power Consumption: <1W
• Housing Material: PC
• Certifications: CE, RoHS

Recommendations

For optimal performance, use with a compatible DMX controller and ensure proper power supply matching the LED strip requirements. Always follow local electrical codes during installation.
