MITON MT-P1280-D8 spojovacia krabica IP65 120x80x80mm svetlosivá ABS

The MITON MT-P1280-D8 is a high-quality hermetic junction box designed for reliable protection of electrical and electronic components in demanding environments. Manufactured from durable ABS plastic with a light grey (RAL 7035) finish, this enclosure offers excellent impact resistance (IK07) and an IP65 ingress protection rating, making it suitable for indoor and outdoor installations. The solid, opaque lid is secured with four plastic screws and features an EPDM rubber gasket to ensure a tight seal against dust and moisture.

Advantages

Robust ABS construction with high impact resistance; IP65 protection against dust and water jets; compact dimensions (120x80x80mm) ideal for space-constrained applications; easy surface or wall mounting with internal bosses for DIN rail or backplate; wide operating temperature range from -25°C to +70°C; CE and RoHS certified for compliance.

Suitable for

• Electrical installations and junction boxes
• Protection of electronic components and connections
• Industrial control systems and automation
• Outdoor and indoor applications requiring dust and water ingress protection

Key specifications

• Brand: MITON
• Model: MT-P1280-D8
• Enclosure Type: Hermetic / Junction Box
• Ingress Protection: IP65
• External Dimensions (L x W x H): 120 x 80 x 80 mm
• Material: ABS Plastic
• Colour: Light Grey (RAL 7035)
• Lid Type: Solid, Opaque
• Lid Fastening: 4x Plastic Screws
• Gasket Material: Rubber / EPDM
• Mounting Type: Surface Mount / Wall Mount
• Operating Temperature: -25°C to +70°C
• Impact Resistance: IK07
• Flammability Rating: UL94-HB
• Internal Mounting: Mounting bosses for DIN rail or backplate
• Cable Entry: Smooth walls for custom drilling / cable glands
• Certifications: CE, RoHS

Recommendations

For optimal installation, use appropriate cable glands and ensure the lid screws are tightened evenly to maintain the IP65 seal. The enclosure can be customized with DIN rails or backplates using the internal mounting bosses.
