Napájací zdroj MEAN WELL DKM10A-05 10W 5V 1A RoHS

The MEAN WELL DKM10A-05 is a compact DC-DC converter in a DIP through-hole package sized approximately 1" x 1". It accepts an input range of 9–18 V DC and provides a single regulated 5 V DC output at up to 1 A, delivering up to 10 W of power. The module is RoHS compliant and designed for PCB mounting where a small, reliable 5 V supply is required.

Advantages

The DKM10A-05 offers an ultra-compact footprint and a through-hole DIP form factor for straightforward PCB mounting and soldering. Its wide input range (9–18 V DC) allows use with various upstream supplies, and the regulated 5 V/1 A output provides stable power for digital circuits and low-power peripherals. RoHS compliance ensures it meets common environmental and safety requirements.

Suitable for

• Embedded systems and microcontroller boards requiring a compact 5 V supply
• Industrial control modules with PCB-mounted power conversion
• Small consumer electronics and peripherals needing a reliable 5 V rail
• Batch production and OEM assemblies (available in bulk packs)

Key specifications

• Input voltage: 9–18 V DC
• Output voltage: 5 V DC
• Output current: 1 A
• Output power: 10 W
• Package: DIP through-hole, PCB mount
• Dimensions: approx. 1" x 1"
• Compliance: RoHS
• Brand / MPN: MEAN WELL DKM10A-05

How to use

Solder the DIP through-hole pins into the PCB footprint, ensuring correct polarity for the input and output pins. Provide an input supply within the 9–18 V DC range and observe the 1 A maximum output current to avoid overload. Place the module with adequate clearance for heat dissipation and follow general PCB layout best practices for power circuits (short traces, proper grounding). Refer to the manufacturer's datasheet for detailed pinout and recommended capacitor placements.

Recommendations

Use the module within the specified input range and do not exceed the 1 A output rating; in high-temperature or high-load conditions provide additional ventilation or spacing to maintain reliable operation.
