Napájací zdroj MEAN WELL DPAN02E-15 2W 15V 0,067A RoHS

The MEAN WELL DPAN02E-15 is a compact PCB-mount DC-DC converter designed for board-level power supply. It accepts an input voltage range of 4.5–9 V DC and provides dual isolated outputs of ±15 V DC at 0.067 A (2 W total). The module is supplied in a SIP through-hole package and meets RoHS environmental requirements.

Advantages

The DPAN02E-15 offers a small footprint suitable for PCB mounting, dual isolated outputs for bipolar power rails, and a SIP through-hole form factor that simplifies mechanical retention and soldering. Its RoHS compliance ensures restriction of hazardous substances and easier integration in compliant designs.

Suitable for

• Board-level power for analog front-ends requiring ±15 V rails
• Signal conditioning and sensor interface circuits
• Industrial control modules with limited space
• Low-power communication and measurement devices

Key specifications

• Manufacturer: MEAN WELL (mean well)
• Model (MPN): DPAN02E-15
• Input voltage: 4.5–9 V DC
• Output: Dual ±15 V DC
• Output current: 0.067 A per rail (total power 2 W)
• Package: SIP through-hole
• Compliance: RoHS
• EAN: 4021087046350

How to use

Mount the DPAN02E-15 on the PCB using the specified through-hole pinout and solder according to standard IPC soldering guidelines. Provide a regulated 4.5–9 V DC input source within the converter's range. Observe correct polarity on the input and route output ±15 V rails to the target circuits, keeping signal and power traces separated as needed to minimize noise. Follow the manufacturer's recommended input/output decoupling and layout practices when available.

Recommendations

For reliable operation, operate the module within its specified input voltage range and keep total output load within the 2 W rating. Ensure adequate spacing and insulation if used near high-voltage or high-temperature components. Verify soldering and board layout for thermal dissipation and noise considerations.
