Napájací zdroj MEAN WELL DPBW06G-05 6W vstup 18-75V výstup 5V

The MEAN WELL DPBW06G-05 is a compact 6W DC-DC converter designed for PCB mounting in a SIP through-hole package. It accepts a wide input range of 18–75 VDC and provides a regulated single output of 5 V suitable for small electronic systems and embedded applications. The module is RoHS compliant and intended for reliable power conversion on circuit boards.

Advantages

This MEAN WELL power adapter offers a wide input voltage range that supports various battery and industrial supply levels, a compact SIP through-hole form factor for straightforward PCB integration, and a regulated 5 V output delivering up to 6 W of power. Its construction follows RoHS standards, making it suitable for projects that require lead-free components and consistent performance in constrained spaces.

Suitable for

• Embedded systems and microcontroller boards
• Industrial control circuits with wide input sources
• Battery-powered equipment and vehicle electronics
• Small instrumentation and communication modules

Key specifications

• Manufacturer: MEAN WELL
• Model (MPN): DPBW06G-05
• Input voltage: 18–75 VDC
• Output: 5 VDC
• Output power: 6 W
• Package: SIP through-hole (PCB mount)
• Standards: RoHS compliant
• EAN: 4021087046251

How to use

Solder the SIP through-hole pins into the PCB according to your board layout and ensure correct polarity on the input and output lines. Provide an appropriate input source within the 18–75 VDC range and verify the output with a multimeter before connecting sensitive loads. Mount the converter with adequate spacing for ventilation and follow the manufacturer’s PCB layout recommendations for grounding and input/output decoupling to ensure stable operation.

Recommendations

Use appropriate input protection (fusing or transient suppression) when connecting to potentially noisy or inductive sources, and avoid exceeding the rated 6 W output to maintain reliable performance and component longevity.
