Napájací zdroj Mean Well PSP-600-48

The Mean Well PSP-600-48 is an AC-DC single-output enclosed power supply delivering 48 V DC at up to 12.5 A (600 W). It accepts a wide AC input range of 88–264 V and meets RoHS requirements. Its compact dimensions (120 mm × 170 mm × 93 mm) make it suitable for installations where space is limited, and each pack contains 8 units.

Advantages

The PSP-600-48 provides a stable 48 V output with 12.5 A maximum current, offers wide-range input capability for international use, and is RoHS compliant. Its enclosed design reduces exposure to internal components while the compact footprint simplifies integration into control cabinets and equipment racks.

Suitable for

• Industrial control systems
• Telecommunications equipment
• LED lighting drivers and signage
• Embedded systems and network devices

Key specifications

• Model: Mean Well PSP-600-48 (PSP-600-48)
• Output: 48 V DC, 12.5 A, single output
• Power: 600 W
• Input voltage: 88–264 V AC
• RoHS compliant
• Dimensions: 120 mm (W) × 170 mm (D) × 93 mm (H)
• Pack quantity: 8 units

How to use

Mount the enclosed power supply in a well-ventilated location and secure it according to the installer’s guidelines. Connect the AC input to the appropriate mains supply within the specified 88–264 V range, observing polarity and grounding requirements. Connect the DC output to your 48 V load, ensuring wiring and load current do not exceed the 12.5 A rating. Verify correct wiring and insulation before powering up.

Recommendations

Install the unit with sufficient clearance for airflow, avoid mounting near heat sources, and use appropriately rated wiring and overcurrent protection sized for 12.5 A output. For critical applications, consider redundancy or surge protection to improve reliability.
