Napájací zdroj MEAN WELL RSDW08F-15, 8 W, 15 V, 0,53 A

MEAN WELL RSDW08F-15 is a compact DC-DC railway single output converter designed for applications requiring a regulated 15 VDC supply at low power. The module accepts a wide input range of 9–36 VDC, delivers up to 0.53 A (8 W) on the single 15 V output, and features 1.5 kVDC input/output isolation. The unit is supplied in a DIP through-hole package and includes a remote ON/OFF control. It is RoHS compliant and intended for batch production and prototyping where a reliable isolated 15 V rail is needed.

Advantages

The RSDW08F-15 offers wide input-voltage compatibility (9–36 VDC), compact DIP through-hole packaging for straightforward PCB assembly, and galvanic isolation of 1.5 kVDC between input and output. Remote ON/OFF control allows easy integration into systems that require power sequencing or external enable/disable. RoHS compliance ensures compatibility with environmental regulations for electronic assemblies.

Suitable for

• Railway and transportation electronics requiring isolated 15 V supply
• Low-power embedded devices and sensors
• Prototyping and PCB through-hole assembly
• Mass production runs (bulk supply packaging)

Key specifications

• Manufacturer: MEAN WELL
• Model (MPN): RSDW08F-15
• Input voltage: 9–36 VDC
• Output voltage/current: 15 VDC, 0.53 A (8 W)
• Isolation: 1.5 kVDC I/O
• Package: DIP through-hole
• Control: Remote ON/OFF
• Compliance: RoHS
• Pack quantity: 600 pcs per pack (as supplied)

How to use

Mount the DIP through-hole module on the PCB following the manufacturer’s pinout and observe correct polarity for input and output connections. Apply an input voltage within the specified 9–36 VDC range and verify the output is 15 VDC under the expected load (up to 0.53 A). Use the remote ON/OFF pin according to the datasheet logic levels to enable or disable the output. Maintain adequate spacing and clearances for the 1.5 kV isolation requirement when designing the PCB layout.
