MEAN WELL RSP-1000-24 960W 1U uzavretý spínaný napájací zdroj 24V 40A s PFC

Delivering 960 watts of continuous power from a compact 1U low-profile metal chassis, the RSP-1000-24 is engineered for demanding industrial and network applications. Active power factor correction (PFC) achieves >0.95, while high efficiency up to 90% reduces energy waste and cooling requirements. With a universal AC input range of 90–264 VAC and full protections including short circuit, overload, over voltage, and over temperature, this power supply ensures reliable operation in critical systems.

Overview

The MEAN WELL RSP-1000-24 is a 24 V DC, 40 A enclosed switching power supply designed for 1U rack-mount and industrial installations. Its built-in DC fan with speed control adjusts cooling based on load and temperature, maintaining optimal performance and extending component life. The output voltage is adjustable from 20 to 26.4 V, allowing fine-tuning for specific requirements. Remote ON/OFF, remote sense, and DC OK signal provide advanced monitoring and control capabilities for integration into complex systems.

What stands out

• High power density: 960 W in a 1U low-profile metal case
• Active PFC with power factor >0.95 for efficient use of AC mains
• Wide input voltage range: 90–264 VAC or 127–370 VDC
• Comprehensive protections: short circuit, overload, over voltage, over temperature
• Remote functions: ON/OFF control, remote sense, DC OK signal
• Adjustable output voltage: 20–26.4 V
• Built-in DC fan with automatic speed control for quiet, efficient cooling
• Certified to UL, CUL, TUV, CB, and CE standards
• High MTBF >100K hours per MIL-HDBK-217F

Technical details

• Output power: 960 W
• Output voltage: 24 V DC (adjustable 20–26.4 V)
• Output current: 40 A
• Ripple & noise: 150 mVp-p max
• Input voltage: 90–264 VAC / 127–370 VDC
• Input frequency: 47–63 Hz
• Efficiency: up to 90%
• Power factor: >0.95 (active PFC)
• Isolation voltage: I/P-O/P 3 kVAC, I/P-FG 2 kVAC, O/P-FG 0.5 kVAC
• Operating temperature: -20 to +70°C
• Cooling: built-in DC fan with speed control
• Protections: short circuit, overload, over voltage, over temperature
• Remote functions: remote ON/OFF, remote sense, DC OK signal
• Certifications: UL, CUL, TUV, CB, CE
• MTBF: >100K hours (MIL-HDBK-217F)
• Housing: metal case, 1U low-profile form factor

Our verdict

The MEAN WELL RSP-1000-24 combines high power output, robust protection, and advanced control features in a space-saving 1U enclosure. It is an excellent choice for industrial automation, telecommunications, and server applications where reliability and efficiency are paramount.
