Napájací zdroj MEAN WELL SKM10B-05 10 W 5 V 18-36 V

The MEAN WELL SKM10B-05 is a DC-DC converter designed for PCB mounting. It accepts a wide input range of 18–36 V DC and delivers a regulated single output of 5 V DC at up to 2 A (10 W). The module comes in a 1" x 1" DIP through-hole package, weighs approximately 18 g, and meets RoHS requirements, making it suitable for space-constrained electronic applications that require a stable low-voltage supply.

Advantages

The SKM10B-05 offers a compact footprint and through-hole DIP form factor for easy PCB assembly, a wide input range that supports various battery and bus voltages, and a regulated 5 V output capable of supplying up to 2 A. Its low weight and RoHS compliance simplify integration into small devices and projects while meeting environmental standards.

Suitable for

• Embedded systems and microcontroller boards
• Industrial control modules with 18–36 V supply rails
• Battery-powered equipment and vehicle electronics
• Small instrumentation and measurement devices

Key specifications

• Manufacturer: MEAN WELL
• Model / MPN: SKM10B-05
• Input voltage: 18–36 V DC
• Output: 5 V DC, 2 A (10 W)
• Package: 1" x 1" DIP through-hole
• Weight: ~18 g
• Standards: RoHS compliant
• EAN: 4021087041560

How to use

Solder the SKM10B-05 into the PCB using the DIP through-hole pads following the board’s footprint and polarity markings. Connect the input to a stable DC source within 18–36 V and route the 5 V output to the load, observing correct polarity. Ensure adequate solder joints and common grounding between the converter and the system. Verify output voltage with a multimeter before connecting sensitive electronics.

Recommendations

Mount the module with proper spacing for heat dissipation and avoid placing heat-sensitive components directly above it. Use input filtering and transient protection on the 18–36 V line if the environment has electrical noise or load transients, and stay within the 2 A output limit to prevent overheating.
