Nástenná zásuvka NRGkick 16A čierna poistka 1A

The NRGkick wall socket 16A is a permanently installed proprietary interface socket designed specifically for use with NRGkick charging units. It provides a dedicated connection point with a maximum charging current of 16 A (up to 11 kW) and includes integrated safety features such as temperature monitoring and automatic current regulation. The socket is supplied as a single unit and is intended for fixed installation on the electrical supply line to serve as the interface for NRGkick charging devices.

Advantages

The proprietary interface prevents unauthorized devices from being connected while allowing immediate connection of an NRGkick charging unit. The socket offers smooth, easy plugging and unplugging due to its optimized contact properties and materials. Built-in temperature monitoring on each phase pin and automatic overheating protection enable the charging unit to regulate or stop current flow if excessive heat is detected. The patented safety connector system prevents arcing by interrupting current flow before contacts separate, and the NRGkick detects wrongly wired sockets and inhibits charging while alerting the user via LED. An additional LED on the Connector Unit provides clear status information, and the connector’s ergonomic design ensures secure engagement and reliable handling.

Suitable for

• Fixed installation in residential or communal building electrical installations
• Locations where freely accessible CEE sockets or conventional wallboxes are unsuitable or not desired
• Creating multiple low-cost charging points for NRGkick charging units

Key specifications

• Manufacturer: NRGkick
• Model: NRGkick wall socket 16A (MPN 20001008, EAN 9120075710510)
• Maximum current: 16 A
• Maximum charging power: up to 11 kW
• Fuse: 1 A (as specified in product title)
• Connection type: proprietary NRGkick interface (no external devices compatible)
• Mounting: permanent installation on supply line

How to use

Install the NRGkick wall socket permanently on the supply line according to applicable electrical codes and have installation carried out by a qualified electrician. Once installed, connect the NRGkick charging unit by engaging the Connector Unit into the wall socket; the socket is automatically recognized by the charging unit and charging current is limited to the socket’s approved value. During charging, status information is displayed via LEDs on the charging and Connector Unit. If the socket temperature or wiring fault is detected, the charging unit will automatically regulate or stop charging and indicate the issue via LED.

Recommendations

Have the wall socket installed and inspected by a licensed electrician. Use only compatible NRGkick charging units with this proprietary interface. Regularly check the socket and connector for visible damage and ensure ventilation around the installation to support heat dissipation.
