OBO Bettermann Typ B Montážna doska V2A nehrdzavejúca oceľ MP R2 2B (7408804)

In industrial control cabinets and distribution enclosures, electricians and panel builders need a reliable way to mount components such as terminal blocks, relays, or contactors. The OBO Bettermann Type B Mounting Plate provides a solid, corrosion-resistant base inside R2 series enclosures. Made from V2A stainless steel (AISI 304), it withstands humid or aggressive environments without rusting, ensuring long-term stability for your electrical installations.

Key specifications

• Product type: Mounting plate
• Material: Stainless steel V2A (AISI 304)
• Dimensions: 200 mm length × 200 mm width × 2 mm thickness
• Compatibility: OBO Bettermann R2 series enclosures
• Mounting position: Internal
• Surface finish: Natural / untreated
• Drilling: Undrilled for custom component mounting
• Colour: Metallic

Why choose it

This mounting plate offers a rust-free solution for demanding environments, both indoor and outdoor. Its undrilled surface allows you to position and secure components exactly where needed, without pre-defined hole patterns limiting your layout. The V2A stainless steel construction provides excellent resistance to corrosion, extending the service life of your enclosure system.

Ideal use cases

• Mounting DIN rail terminal blocks and electrical components inside R2 enclosures
• Industrial control panels in food processing, chemical plants, or coastal areas
• Custom panel builds where components need a stable, corrosion-resistant base
• Retrofitting existing R2 enclosures with an additional mounting surface

Good to know

The plate is designed for internal installation within OBO Bettermann R2 series enclosures. It comes with a natural, untreated surface, ready for drilling or tapping as required. Material conforms to DIN EN 10088 for stainless steel.
