PoE adaptér Hikvision LAS60-57CN-RJ45

The Hikvision LAS60-57CN-RJ45 PoE adapter is a Gigabit Ethernet midspan injector that supplies power over standard Category 5 twisted-pair cabling following IEEE 802.3af and IEEE 802.3at (PoE/PoE+) specifications. It provides up to 60W output to connected devices while presenting the required PoE signature and power classification to Power Sourcing Equipment (PSE) before applying power.

Advantages

This PoE adapter delivers up to 60W output for powered devices and supports both 802.3af and 802.3at standards for wide compatibility. It includes LED indicators for power and PoE status, and built-in protection against over-current and short-circuit conditions. The compact black enclosure and lightweight design (185 x 70.8 x 37 mm, 0.473 kg) simplify installation in varied environments with 100–240 V, 50–60 Hz input.

Suitable for

• Powering PoE and PoE+ network devices such as IP cameras and access points
• Adding PoE capability to non-PoE network switches
• Use in small offices, retail, and other installations requiring a single midspan injector

Key specifications

• Output power: up to 60W
• Standards: IEEE 802.3af and IEEE 802.3at
• Ports: 2 × RJ-45 (Gigabit Ethernet)
• Input voltage: 100–240 V, 50–60 Hz
• Indicators: Power and PoE status LEDs
• Protection: Over-current and short-circuit protection
• Dimensions: 185 × 70.8 × 37 mm
• Weight: 0.473 kg
• Colour: Black

How to use

Connect the adapter's AC input to a mains outlet using the appropriate power cord. Link the network switch or injector input port to your network using a Category 5 (or higher) Ethernet cable, then connect the device requiring power to the PoE output port. The adapter negotiates power with the connected device via the PoE signature circuit and, after classification, supplies up to 60W as needed. Monitor the LEDs to verify power and PoE status during installation.

Recommendations

Install the adapter in a ventilated area away from direct heat sources. Use quality Cat5e or Cat6 cables for reliable Gigabit performance and to minimize power loss. Verify that the powered device is compatible with 802.3af/at and that its power requirement does not exceed the adapter's 60W output.
