PULSAR AWZ626 6-kanálový SPDT reléový modul

The PULSAR AWZ626 is a high-quality 6-channel relay module designed for use in alarm systems, access control, CCTV, and automation applications. This open PCB module features SPDT (Single Pole Double Throw) relays with NO/NC contact configuration, providing versatile switching capabilities. With galvanic isolation and LED indicators for each relay, it ensures reliable performance and easy status monitoring.

Advantages

Compact and efficient design with screw terminals for secure connections. Low power consumption and wide operating temperature range make it suitable for various environments. Galvanic isolation protects sensitive control circuits.

Suitable for

• Alarm systems
• Access control systems
• CCTV installations
• Industrial automation

Key specifications

• Number of Channels: 6
• Relay Type: SPDT (Single Pole Double Throw)
• Contact Configuration: NO/NC (Normally Open/Normally Closed)
• Max. Switching Voltage: 30V DC / 50V AC
• Max. Switching Current: 1A
• Module Supply Voltage: 10V DC - 16V DC
• Current Consumption (all relays active): ~60mA @ 12V DC
• Input Control Voltage: 10V DC - 16V DC
• Indicators: 6x LED (relay status)
• Terminal Type: Screw terminals
• Mounting: Screw mounting (4x mounting holes)
• Operating Temperature: -10°C to +50°C
• Protection: Galvanic isolation
• Enclosure: Open PCB module
• Compliance: CE

Recommendations

For optimal performance, ensure the supply voltage is within the specified range and use appropriate screw terminals for connections. This module is ideal for low-voltage switching applications.
