Ručný skrutkovač Gedore 1616048

Gedore 1616048 is a fully insulated manual screwdriver designed for work on slotted and Phillips (PH) screws. The tool features a blade made from Gedore molybdenum‑vanadium‑Plus tempered steel and a three-component Power‑Grip3 handle with a hanging hole. The screwdriver is VDE certified for insulation up to 1000 V according to EN 60900 / IEC 60900 and is supplied in an environmentally friendly cardboard box.

Advantages

The fully insulated blade and VDE certification provide electrical protection up to 1000 V. The Power‑Grip3 three-component handle offers an ergonomic shape for precise, fatigue‑reducing operation and a positive‑fit joint between handle and blade ensures optimal force transmission. Drive type is marked on the handle end for quick identification. Durable molybdenum‑vanadium‑Plus tempered steel blade increases longevity and wear resistance.

Suitable for

• Working on slotted and cross‑head (PH) screws
• Electrical installation and maintenance where insulation up to 1000 V is required
• Professional workshops and precise DIY tasks

Key specifications

• Brand: Gedore
• Model / MPN: 1616048
• EAN: 4010886826140
• Insulation: VDE insulated up to 1000 V (EN 60900 / IEC 60900)
• Blade material: Gedore molybdenum‑vanadium‑Plus tempered steel
• Handle: 3-component Power‑Grip3 with hanging hole
• Length / dimensions: approximately 162 mm × 42 mm (as supplied)
• Weight: 0.575 kg

How to use

Select the correct drive (slotted or PH) and position the blade into the screw head. Apply steady axial pressure and turn the handle clockwise to tighten or counterclockwise to loosen. Use the marked drive type on the handle end to confirm the screwdriver type. For electrical work, ensure circuits are de‑energized where possible and follow local safety procedures before starting work.

Recommendations

Store the screwdriver in a dry place and inspect the insulation before each use. Do not use the insulated screwdriver if the handle or blade insulation is damaged. For live electrical work, follow applicable safety standards and use appropriate personal protective equipment.
