SATEL BE Wave HYBRID 128 alarmová ústredňa pre ABAX 2, LAN, WiFi

The SATEL BE Wave HYBRID 128 is a hybrid alarm control panel that combines wired and wireless security, supporting up to 128 zones. It features a built-in ABAX 2 transceiver for 64 wireless zones and offers LAN and WiFi connectivity for remote management via the INTEGRA CONTROL app or GUARDX web browser. Ideal for residential and commercial installations, this panel provides flexible expansion and high security.

Advantages

Hybrid design allows integration of both wired and wireless detectors. Built-in ABAX 2 wireless technology ensures reliable 433 MHz communication. Remote control via smartphone app and web interface. Expandable to 128 zones and 64 outputs. Supports up to 32 partitions and 248 users.

Suitable for

• Residential security systems
• Small to medium commercial premises
• Hybrid installations combining existing wired sensors with wireless devices

Key specifications

• System Type: Hybrid (Wired & Wireless)
• Max. Wired Zones: 8 (expandable to 128)
• Max. Wireless Zones: 64 (via built-in ABAX 2 transceiver)
• Max. Programmable Outputs: 4 (on-board, expandable to 64)
• Max. Users: 240 + 8 administrators
• Partitions/Areas: 32
• Keypads Supported: Up to 8 (LCD, touch screen, partition keypads)
• Event Log Capacity: 22527 events
• Communication Modules: Built-in PSTN dialer, supports optional GSM/GPRS and Ethernet modules
• Wireless Technology: ABAX 2 (433 MHz)
• Power Supply Input: 18V AC, 40 VA (transformer required)
• Auxiliary Power Output: 12V DC, 2A
• Timers: 64
• Firmware Update: Via FLASH memory
• Security Grade: EN 50131 Grade 2
• Remote Control: Via mobile app (INTEGRA CONTROL) and web browser (GUARDX) with optional modules
• On-board Modules: PSTN dialer, ABAX 2 wireless transceiver

Recommendations

For optimal performance, use SATEL ABAX 2 wireless detectors and keypads. Ensure proper transformer (18V AC, 40 VA) is installed. Configure remote access via LAN or WiFi for full functionality.
