SATEL LR-CL Fresnelova šošovka pre dlhodosahový záclonový PIR detektor

The SATEL LR-CL is a high-quality Fresnel lens designed for long-range curtain detection in compatible SATEL PIR motion detectors. This replacement or customization lens provides precise focusing of infrared energy, enabling reliable detection up to 15 meters when used with detectors like the OPAL PRO series. Manufactured from durable optical plastic, the LR-CL ensures consistent performance in indoor environments.

Advantages

Optimized for long-range curtain applications, the LR-CL lens offers narrow beam optics that create a precise detection curtain, minimizing false alarms. Its easy-to-replace design allows for quick customization of compatible SATEL detectors, extending their functionality without replacing the entire unit. The transparent material ensures minimal signal loss and reliable passive infrared (PIR) focusing.

Suitable for

• Replacement of standard lenses in SATEL AGATE, AGATE PET, OPAL, OPAL PLUS, OPAL PRO, JADE, and JADE PET series detectors
• Customizing detection patterns for long-range curtain coverage in indoor security systems
• Upgrading existing PIR detectors to achieve a narrow, focused detection zone

Key specifications

• Lens Type: Fresnel
• Detection Pattern: Long-range curtain
• Compatible Detectors: SATEL AGATE, AGATE PET, OPAL, OPAL PLUS, OPAL PRO, JADE, JADE PET series
• Application Environment: Indoor (internal component of compatible detector)
• Material: High-quality optical plastic
• Optical Zones: Multiple narrow beams for precise curtain effect
• Typical Detection Range: Up to 15 meters (with compatible detectors like OPAL PRO)
• Purpose: Replacement or customization lens for PIR motion detectors
• Installation Type: Internal, user-replaceable
• Color: Transparent
• Optical Principle: Passive Infrared (PIR) focusing
• Environmental Resistance: Designed for stable indoor environments within detector housing

Recommendations

Ensure compatibility with your specific SATEL detector model before purchase. The LR-CL lens is intended for indoor use only and should be installed by a qualified technician to maintain optimal performance and security system integrity.
