Schneider Electric hlavica svetelného tlačidla ZB5AW343

The Schneider Electric ZB5AW343 is a high-quality illuminated push button head from the Harmony XB5 range, designed for industrial control applications. This flush, spring return actuator features a green cap and is unmarked, providing clear visual indication. It is compatible with Harmony XB5 bodies and light blocks, ensuring easy integration into existing systems.

Advantages

This push button head offers exceptional durability with a mechanical life of 10,000,000 cycles. It is built to withstand harsh environments, with IP66, IP67, IP69, and IP69K protection ratings on the front face, as well as NEMA 13 and NEMA 4X ratings. The plastic bezel and robust construction ensure reliable performance in demanding conditions.

Suitable for

• Industrial control panels
• Machine control stations
• Automation systems
• Process control applications

Key specifications

• Product Type: Head for Illuminated Push Button
• Range: Harmony XB5
• Bezel Material: Plastic
• Mounting Diameter: 22 mm
• Actuator Head Type: Flush, Spring Return
• Actuator Color: Green
• Cap/Lens Color: Green
• Shape of Head: Round
• IP Degree of Protection: IP66, IP67, IP69, IP69K (front face)
• NEMA Rating: NEMA 13, NEMA 4X (front face)
• Operating Temperature: -40...70 °C
• Storage Temperature: -40...70 °C
• Mechanical Durability: 10,000,000 cycles
• Vibration Resistance: 5 gn (10-500 Hz) conforming to IEC 60068-2-6
• Shock Resistance: 30 gn (18 ms) for half sine wave acceleration conforming to IEC 60068-2-27
• Compatibility: For use with Harmony XB5 body and light block
• Standards: EN/IEC 60947-1, EN/IEC 60947-5-1, UL 508, CSA C22.2 No 14, JIS C 4520

Recommendations

For optimal performance, pair this push button head with a compatible Harmony XB5 body and light block. Ensure proper installation to maintain the high IP and NEMA protection ratings. This product is ideal for applications requiring reliable and durable control components.
