SHIVERPEAKS BS54030-SET sada páčkových svoriek konektorov, 25-dielna, 2/3/5-pólová, 0,14-4,0 mm², 400 V, 32 A, čierna

Lever-nut wire connector set providing tool-free, reusable connections for solid, stranded, and fine-stranded conductors from 0.14 to 4.0 mm². The spring clamp mechanism with lever actuation ensures secure, vibration-resistant joints rated up to 400 V and 32 A, making it ideal for junction boxes, lighting installations, and general electrical wiring.

Advantages

This set includes 25 connectors in three pole configurations: 10 × 2-pole, 10 × 3-pole, and 5 × 5-pole. The transparent housing allows visual inspection of the connection, while the lever design enables quick insertion and release without special tools. Conductors are clamped by a tinned copper spring, and the PA66 insulation provides high temperature resistance up to 105 °C. Connectors are reusable, reducing waste and installation time.

Suitable for

• Electrical junction boxes and distribution boards
• Lighting installations and luminaire wiring
• Connecting solid, stranded, and fine-stranded copper conductors
• Applications requiring maintenance-free, vibration-proof connections
• DIY and professional electrical work

Key specifications

• Connector type: Lever-nut (spring clamp, lever operated)
• Total connectors: 25 pieces (10 × 2-pole, 10 × 3-pole, 5 × 5-pole)
• Wire range: 0.2 - 4.0 mm² solid/stranded; 0.14 - 4.0 mm² fine-stranded (AWG 24 - 12)
• Rated voltage: 400 V
• Rated current: 32 A
• Insulation material: PA66 (polyamide 66)
• Conductor material: Tinned copper
• Lever material: PC (polycarbonate)
• Max operating temperature: 105 °C
• Color: Black

Recommendations

For reliable, code-compliant splices without twisting or soldering, this lever-nut set is an excellent choice. Always verify conductor size and strip length before insertion, and ensure the lever is fully closed for a secure connection.
