Siemens SIMATIC DP PROFIBUS DP konektor, axiálny vývod kábla, do 12 Mbit/s, 6ES7972-0BB12-0XA0

The Siemens SIMATIC DP PROFIBUS DP Connector (6ES7972-0BB12-0XA0) is a high-performance bus connector designed for reliable data transmission in industrial automation networks. With support for data rates up to 12 Mbit/s, this connector ensures fast and stable communication between PROFIBUS DP devices. Its axial (straight) cable outlet and screw terminal connection simplify installation, while the integrated terminating resistor with switchable ON/OFF function provides flexible network termination. The fully shielded metal housing offers excellent electromagnetic compatibility (EMC) protection, making it suitable for harsh industrial environments.

Advantages

This connector delivers robust performance with a wide operating temperature range (-25 °C to +60 °C) and IP20 degree of protection. The screw terminals allow secure and tool-free wiring of PROFIBUS DP standard cables with diameters from 6.5 mm to 8.0 mm. The integrated bus termination switch eliminates the need for external terminators, reducing installation complexity and cost.

Suitable for

• Connecting SIMATIC S7-300/400/1200/1500 and other PROFIBUS DP devices
• Industrial automation networks requiring high-speed data transmission
• Applications where axial cable outlet and straight connector orientation are preferred

Key specifications

• Product Type: PROFIBUS DP Connector
• Series: SIMATIC DP
• Data Transmission Rate: Up to 12 Mbit/s
• Cable Outlet Direction: Axial (Straight)
• Bus Connection Type: D-sub 9-pin male
• Cable Connection Type: Screw terminals (4 terminals for data lines A, B, and shield)
• Integrated Terminating Resistor: Yes, switchable
• Bus Termination Switch: Yes (ON/OFF)
• Shielding: Fully shielded metal housing
• Housing Material: Metal (Zinc Die-Cast)
• Operating Temperature: -25 °C to +60 °C
• Storage Temperature: -40 °C to +70 °C
• Relative Humidity: 95% (non-condensing)
• Degree of Protection: IP20
• Compatible Cable Type: PROFIBUS DP Standard Cable
• Cable Diameter Range: 6.5 mm to 8.0 mm
• Mounting Type: Direct plug-in

Recommendations

For optimal performance, use with Siemens SIMATIC S7 controllers and PROFIBUS DP standard cables. Ensure the bus termination switch is set correctly at the ends of the bus segment.
