Siemens SIMATIC S7-1200 G2 CPU 1212C DC/DC/DC 8DI/6DO 6ES7212-1AG50-0XB0

The Siemens SIMATIC S7-1200 G2 CPU 1212C DC/DC/DC is a compact and powerful controller designed for a wide range of automation tasks. With 8 digital inputs, 6 digital outputs, and 2 analog inputs, it offers a balanced I/O configuration for small to medium-sized applications. The DC/DC/DC power supply ensures reliable operation in industrial environments.

Advantages

High performance in a compact design, easy integration via PROFINET, and flexible expansion options with signal boards and modules. The integrated motion and PID control functions reduce the need for additional hardware.

Suitable for

• Machine control in manufacturing
• Building automation systems
• Process control applications
• Educational and training setups

Key specifications

• CPU model: CPU 1212C
• Power supply: 20.4-28.8 V DC
• Digital inputs: 8 (24 V DC)
• Digital outputs: 6 (transistor, 0.5 A each)
• Analog inputs: 2 (0-10 V DC)
• Program/data memory: 75 KB
• Load memory: 2 MB integrated
• Communication: 1 x PROFINET (Ethernet)
• Mounting: DIN rail
• Operating temperature: 0 °C to 50 °C

Recommendations

For optimal performance, use the TIA Portal for programming and consider adding signal modules for additional I/O requirements.
