Siemens SIMATIC S7-1200 SM 1232 analógový výstupný modul, 8 x 14 bit, 6ES7232-4HF50-0XB0

The Siemens SIMATIC S7-1200 SM 1232 analog output module (6ES7232-4HF50-0XB0) is a high-performance signal module designed for the SIMATIC S7-1200 controller family. It provides 8 analog outputs with 14-bit resolution for voltage and 13-bit for current, ensuring precise control in industrial automation applications. The module supports voltage outputs (±10V, 0-10V) and current outputs (0-20mA, 4-20mA), with electrical isolation between channels and the backplane bus for reliable operation in noisy environments.

Advantages

This module offers high accuracy (0.3% for voltage, 0.4% for current) and fast conversion time of approximately 1 ms per channel. It includes diagnostic functions for wire break (current), short circuit (voltage), and internal errors, enhancing system reliability. The compact design allows DIN rail mounting, saving space in control cabinets.

Suitable for

• Industrial automation and process control systems
• Precision analog output applications requiring multiple channels
• Integration with Siemens SIMATIC S7-1200 PLCs

Key specifications

• Product Type: Analog Output Signal Module
• Series: SIMATIC S7-1200
• Number of Analog Outputs: 8
• Output Signal Types: Voltage, Current
• Voltage Output Ranges: ±10V, 0-10V
• Current Output Ranges: 0-20mA, 4-20mA
• Resolution (Voltage Output): 14 bit
• Resolution (Current Output): 13 bit
• Isolation: Yes (between channels and backplane bus)
• Supply Voltage (from backplane bus): DC 24V
• Power Consumption (from backplane bus): Max. 2.5 W
• Permissible Load Resistance (Voltage): > 1 kOhm
• Permissible Load Resistance (Current): < 500 Ohm
• Accuracy (Voltage Output): 0.3% (full scale)
• Accuracy (Current Output): 0.4% (full scale)
• Conversion Time: Approx. 1 ms per channel
• Diagnostics Functions: Wire break (current), short circuit (voltage), internal error
• Mounting Type: DIN rail
• Operating Temperature (Horizontal): 0 °C to 50 °C
• Operating Temperature (Vertical): 0 °C to 40 °C

Recommendations

For optimal performance, use this module with a Siemens SIMATIC S7-1200 CPU and ensure proper grounding and shielding. Refer to the product manual for detailed installation and configuration instructions.
