Siemens SIVACON 8GK držiak zbernice 8GK99100KK08, balenie 5 ks, čierny, 12x5–30x10 mm

In industrial and commercial power distribution, electricians and panel builders need a reliable way to mount busbars inside SIVACON 8GK distribution boards. The Siemens 8GK99100KK08 busbar holder provides a snap-on solution for securing flat copper busbars with dimensions from 12x5 mm up to 30x10 mm. Supplied in a pack of 5, these black plastic holders are halogen-free and designed for use within the SIVACON 8GK modular system.

Key specifications

• Product type: Busbar holder / support
• Series: SIVACON 8GK
• Quantity per pack: 5 pieces
• Material: Plastic
• Supported busbar dimensions (W x H): 12x5 mm, 12x10 mm, 15x5 mm, 20x5 mm, 25x5 mm, 30x5 mm, 30x10 mm
• Mounting type: Snap-on / clip-on
• Rated insulation voltage (Ui): 1000 V
• Rated impulse withstand voltage (Uimp): 8 kV
• Colour: Black
• Environmental features: Halogen-free
• System compatibility: SIVACON 8GK modular system
• Component type: Accessory for power distribution
• Standard compliance: IEC 61439
• Operating temperature range: -25 to +55 °C

Why choose it

The snap-on mounting mechanism speeds up installation, while the halogen-free plastic construction supports modern safety requirements. With a rated insulation voltage of 1000 V and impulse withstand voltage of 8 kV, these holders are built for demanding low-voltage distribution tasks.

Ideal use cases

• Mounting busbars in SIVACON 8GK distribution boards and cabinets
• Panel building and switchgear assembly
• Retrofitting or expanding existing SIVACON 8GK installations

Good to know

The holder accepts multiple busbar sizes, offering flexibility in design. It is an accessory within the SIVACON 8GK system and complies with IEC 61439 for low-voltage switchgear and controlgear assemblies.
