Sieťový adaptér Lenovo 2.5G Ethernet sieťový — PCIe / 2,5 Gigabit Ethernet

Lenovo 2.5G Ethernet network is a PCIe network adapter designed to add a 2.5 Gigabit wired LAN interface to desktop PCs or servers. It expands network throughput beyond standard 1 Gbps connections, enabling faster file transfers, improved media streaming performance, and lower latency for networked applications. The adapter installs into a free PCIe slot and provides a standard RJ‑45 Ethernet port for use with existing network infrastructure.

Advantages

This network adapter delivers up to 2.5 Gbps wired throughput while remaining compatible with conventional Ethernet switches and cabling. Using a PCIe interface ensures direct access to system bandwidth for stable data transfer rates. The card is suitable for environments where increased LAN performance is required without replacing existing network switches or upgrading to fiber. Its design supports plug‑and‑play installation on compatible systems and offers a straightforward upgrade path from 1 Gbps Ethernet.

Suitable for

• Upgrading desktop or small server network throughput from 1 Gbps to 2.5 Gbps
• High‑speed file transfers and backups on local area networks
• Improved media streaming and low‑latency gaming or collaboration
• Workstations handling large datasets, video editing, or virtualization

Key specifications

• Interface: PCI Express (PCIe) expansion card
• Network speed: up to 2.5 Gigabit per second (2.5 Gbps) with backward compatibility to 1 Gbps and 100 Mbps
• Connector: standard RJ‑45 Ethernet port
• Supported media: twisted pair copper cabling (Cat5e/Cat6 recommended for 2.5 Gbps)
• Form factor: low‑profile capable card suitable for desktop and server chassis

How to use

Power down the computer and unplug it from the mains before installation. Insert the adapter into a compatible PCIe slot and secure it to the chassis with the bracket screw. Connect the network cable to the RJ‑45 port and plug the other end into a switch, router, or wall jack. Power on the system and install any required drivers if the operating system does not automatically recognize the card. After installation, configure network settings in the operating system or management software to match your LAN requirements.

Recommendations

For reliable 2.5 Gbps performance, use Cat5e or Cat6 cabling and ensure the connected switch or router supports 2.5G operation. Verify BIOS/UEFI and operating system compatibility before installation, and keep network drivers up to date. If low profile mounting is required, confirm availability of the appropriate bracket and clearance inside the chassis.
