Silicon Power DDR5 5600 CL46 16GB SP016GBLVU560F02

Silicon Power SP016GBLVU560F02 is a 16 GB DDR5 288‑pin DIMM ECC memory module designed for PCs and servers. Running at 5600 MT/s with CAS latency CL46 and a nominal voltage of 1.1 V, this single 1 x 16 GB module delivers higher bandwidth and responsiveness for multi‑core systems while providing on‑die ECC for improved data integrity in workstation and server environments.

Advantages

The module offers significantly faster transmission speeds and greater bandwidth compared with typical DDR4 memory, while its 1.1 V operating voltage reduces power consumption. On‑die ECC enhances reliability by detecting and correcting certain memory errors, and the DDR5 architecture—featuring independent 32‑bit channels per module, increased banks and longer burst length—improves overall computing efficiency and multi‑tasking performance.

Suitable for

• Workstation systems running memory‑intensive applications
• Server platforms and small servers requiring ECC support
• PC upgrades to DDR5‑capable motherboards and 13th Gen Intel® Core™ systems that support DDR5

When it may not be suitable

This DDR5 module is not compatible with motherboards that only support DDR4 memory; it requires a DDR5‑capable motherboard and a compatible CPU. Systems that do not need ECC or high memory bandwidth may not benefit noticeably from this module compared with lower‑spec memory.

Key specifications

• Capacity: 16 GB (1 x 16 GB)
• Memory type: DDR5
• Speed: 5600 MT/s
• CAS latency: CL46
• Voltage: 1.1 V
• Form factor: 288‑pin DIMM (UDIMM)
• Error correction: On‑Die ECC

How to use

Install the module into a vacant DDR5 DIMM slot on a compatible motherboard, following the motherboard manufacturer’s instructions for memory installation and safe handling (power off the system and discharge static before installation). For optimal performance, populate channels according to the motherboard’s recommended slot population and enable any platform memory settings in BIOS/UEFI if required.

What to consider before purchase

• Check motherboard and CPU support for DDR5 memory and the supported speed (5600 MT/s)
• Verify motherboard slot type: 288‑pin DIMM (UDIMM)
• Ensure your system requires or can take advantage of ECC features
• Confirm physical clearance in the case and compatibility with existing modules if mixing

Recommendations

For best results, use this 16 GB DDR5 5600 MT/s module paired with a DDR5‑compatible motherboard and CPU, populate memory channels according to the motherboard manual, and enable relevant BIOS/UEFI settings to achieve advertised speeds and stability.
