Silicon Power SP032GBLVU560F02 Desktop DIMM, 32 GB x1, DDR5, 5600 MHz, CL46, 1,1 V - 32 GB - DDR5

Silicon Power DDR5 32GB 5600 MT/s memory module (1×32GB) is unbuffered desktop RAM designed for PC upgrades and new systems. It provides DDR5 performance with a data transfer rate of 5600 MT/s, CAS latency CL46 and operates at 1.1 V. The single-module kit increases available memory capacity for multitasking, content creation and demanding applications. Module dimensions are 133.4 × 31.3 mm. RoHS compliance is declared.

Advantages

The module offers a high data transfer rate for improved bandwidth compared with earlier memory generations, a large 32 GB capacity in a single DIMM for simpler upgrades, and low operating voltage that can reduce power consumption. Its unbuffered (non-ECC) design is suitable for standard desktop systems.

Suitable for

• Desktop PC upgrades to increase system memory
• New desktop builds requiring a single 32 GB DDR5 module
• Multitasking, content creation and general productivity workloads
• Environments where RoHS compliance is required

Key specifications

• Memory type: DDR5
• Capacity: 32 GB (single module)
• Configuration: 1 × 32 GB
• Data transfer rate: 5600 MT/s
• CAS latency: CL46
• Operating voltage: 1.1 V
• Buffered type: Unregistered (unbuffered)
• Module dimensions (H × W): 31.3 mm × 133.4 mm
• Compliance: RoHS

How to use

Power down the PC and disconnect from the mains before installing the module. Open the desktop case, locate an empty compatible DDR5 DIMM slot on the motherboard, align the module notch with the slot key and press firmly until the retaining clips click into place. After installation, reconnect power, start the system and verify that the BIOS/UEFI recognises the new 32 GB module and that the system is configured to run at the intended speed.

Recommendations

Use this module in motherboards that support DDR5 memory and check the motherboard manual for supported speeds and recommended slot population. For optimal stability, install compatible modules of the same type and capacity and update BIOS/UEFI firmware if required.
