Sygonix kamerový kábel SY-6441782 - 10m CCTV video a napájací kábel, BNC na BNC + DC

This combined video and power cable eliminates the need for separate runs when installing CCTV cameras. The SY-6441782 carries analog HD video (up to 8MP) and 12V DC power over a single 10-metre black cable, with BNC plugs for video and DC connectors for power.

Highlights

• All-in-one video and power transmission for security cameras
• Supports CVBS, AHD, TVI, and CVI signals up to 8MP
• 75 Ohm coaxial video core with integrated 2-core power cable
• Nickel-plated connectors for reliable contact
• Robust PVC jacket for general indoor/outdoor use

In daily use

Connect the BNC plugs between camera and DVR, and the DC plug/socket between camera and power supply. Plug-and-play installation saves time and reduces cable clutter in surveillance setups.

Full specifications

• Cable length: 10 m
• Cable type: Combined video and power cable
• Video connectors: BNC plug (both ends)
• Power connectors: DC plug (male) to DC socket (female)
• Video signal compatibility: CVBS, AHD, TVI, CVI (up to 8MP)
• Video impedance: 75 Ohm
• Conductor material: Copper
• Jacket material: PVC
• Connector plating: Nickel-plated
• Cable design: Coaxial (video) with integrated 2-core power cable
• Power compatibility: Standard 12V DC CCTV power

Final note

A practical single-cable solution for CCTV installations, combining video and power in one durable black jacket.
