Sygonix SY-6441788 20m BNC + DC predlžovací kábel pre bezpečnostnú kameru, čierna

Extending the reach of your CCTV camera often means dealing with two separate cables: one for video and one for power. The Sygonix SY-6441788 solves this by combining both into a single 20-metre cable, so you can place your camera where it's needed without messy cable runs.

Who is it for

This cable is ideal for CCTV installers and DIY security enthusiasts who need to extend the distance between a surveillance camera and a DVR or power supply. It works with analog HD cameras (AHD, TVI, CVI) as well as standard CVBS cameras.

Main features

• 20 m combined video and power extension cable
• Video: BNC male to BNC male, 75 Ohm coaxial
• Power: DC male 2.1mm/5.5mm to DC female 2.1mm/5.5mm
• Supports 12V DC power for cameras
• Black PVC jacket for durability

Specifications

• Cable length: 20 m
• Video connector A: BNC male
• Video connector B: BNC male
• Power connector A: DC male (2.1mm / 5.5mm)
• Power connector B: DC female (2.1mm / 5.5mm)
• Video signal compatibility: Analog (CVBS, AHD, TVI, CVI)
• Power compatibility: DC 12V
• Video cable impedance: 75 Ohm
• Cable colour: Black
• Jacket material: PVC

Tips

When routing the cable outdoors, protect the connectors from moisture to maintain signal quality. For longer runs, ensure your power supply can handle the voltage drop over the distance.
