Synergy 21 LED Controller EOS 10 ZigBee CC Controller + napájací zdroj 2-kanál 50W CCT

The Synergy 21 LED Controller EOS 10 is a high-performance ZigBee 3.0 CC controller with integrated power supply, designed for professional CCT (Tunable White) LED lighting systems. This 2-channel controller delivers up to 50W output power, enabling precise warm white and cold white control for dynamic lighting scenes.

Advantages

Seamless integration with ZigBee 3.0 smart home ecosystems, including Philips Hue, Amazon Echo Plus, Homey, and Samsung SmartThings. The built-in power supply simplifies installation, while PWM dimming technology ensures flicker-free operation from 0.1% to 100%. Robust protection features (overload, short circuit, over temperature) guarantee long-term reliability.

Suitable for

• Residential and commercial CCT LED lighting projects
• Smart home automation with ZigBee 3.0 hubs
• Retrofit and new installations requiring a compact, all-in-one controller

Key specifications

• Product Type: LED Controller
• Control Protocol: ZigBee 3.0
• LED Type Compatibility: CCT (Tunable White) LEDs
• Number of Channels: 2 (Warm White + Cold White)
• Max Output Power: 50 W
• Input Voltage: 200-240 V AC
• Output Voltage: 24 V DC
• Max Output Current: 2.1 A
• Dimming Technology: PWM (Pulse Width Modulation)
• Dimming Range: 0.1% - 100%
• Integrated Power Supply: Yes
• Protection Features: Overload, Short Circuit, Over Temperature
• Operating Temperature: -20°C to +45°C
• Housing Material: Plastic
• IP Rating: IP20
• Smart Home Compatibility: Philips Hue, Amazon Echo Plus, Homey, Samsung SmartThings (ZigBee 3.0 compatible)
• Control Method: Wireless (ZigBee)
• Certifications: CE, RoHS

Recommendations

For optimal performance, pair with a compatible ZigBee 3.0 gateway. Ensure proper ventilation and avoid exposure to moisture. Professional installation recommended.
