Synergy 21 LED Flex Strip 2835 - 60 WW Pixel DC24V WS2811 IP65

The Synergy 21 LED Flex Strip 2835 is a high-quality, individually addressable LED strip designed for dynamic lighting effects. With 60 SMD 2835 LEDs per meter and WS2811 control IC, it offers pixel-level control for stunning animations and color sequences. Operating at DC 24V, this IP65-rated strip is suitable for both indoor and outdoor use, protected against dust and water jets.

Advantages

Individually addressable pixels allow for creative lighting designs. The warm white (WW) color temperature (2700K-3000K) provides a cozy ambiance. Self-adhesive backing ensures easy installation on various surfaces. High flexibility and cuttable segments every 3 LEDs enable custom lengths.

Suitable for

• Architectural accent lighting
• Signage and channel letters
• Event and stage decoration
• Retail display lighting
• Outdoor landscape lighting (protected from direct immersion)

Key specifications

• LED Type: SMD 2835
• LED Quantity: 60 LEDs/meter
• Control IC: WS2811
• Addressability: Individually Addressable (Pixel Control)
• Pixels per Meter: 20 pixels/meter (3 LEDs per pixel)
• Light Color: Warm White (WW)
• Color Temperature: 2700K - 3000K
• Operating Voltage: DC 24V
• Ingress Protection: IP65
• Power Consumption: Approx. 12W/meter
• Beam Angle: 120°
• Cuttable Segments: Every 3 LEDs (or every pixel)
• Connectivity: 3-pin JST SM connector (Data, VCC, GND)
• Backing: Self-adhesive (3M tape)
• Lifespan: >50,000 hours
• Dimmable: Yes, via compatible controller
• Operating Temperature: -20°C to +50°C
• CRI: >80 Ra
• Flexibility: Highly Flexible
• Application Environment: Indoor & Outdoor (protected from direct immersion)

Recommendations

For optimal performance, use with a compatible 24V power supply and a WS2811 controller. Ensure proper waterproofing for outdoor installations. Test the strip before cutting to length.
