Synology RS6426XS+ 16-Bay 3U Rackmount SAN Storage Server, Intel Xeon D-1739, 16GB DDR4 ECC, 10GbE

The Synology RS6426XS+ is a high-performance 16-bay rackmount SAN storage server designed for demanding business environments. Powered by an Intel Xeon D-1739 8-core processor and 16GB DDR4 ECC RDIMM memory, it delivers exceptional data throughput with sequential read speeds up to 6200 MB/s and write speeds up to 4000 MB/s. Ideal for virtualization, backup, and file sharing, this 3U unit supports hot-swappable SATA drives and offers dual 10GbE plus dual 1GbE connectivity for flexible network integration.

Advantages

With redundant 800W power supplies and a 5-year warranty, the RS6426XS+ ensures maximum uptime and reliability. Its Synology Hybrid RAID (SHR) support simplifies storage management while providing data protection. The included DiskStation Manager (DSM) operating system offers a comprehensive suite of applications for backup, surveillance, and collaboration.

Suitable for

• Small to medium businesses requiring centralized storage
• Virtualization environments (VMware, Hyper-V)
• High-availability backup and disaster recovery
• Media production teams needing fast shared storage

Key specifications

• CPU: Intel Xeon D-1739 (8 cores)
• Memory: 16GB DDR4 ECC RDIMM (expandable to 128GB)
• Drive Bays: 16 x 3.5"/2.5" SATA HDD/SSD (hot-swappable)
• Network: 2 x 10GbE RJ-45, 2 x 1GbE RJ-45
• PCIe: 2 x Gen4 x8 slots
• USB: 2 x USB 3.2 Gen 1
• Form Factor: 3U Rackmount
• Power: Redundant 2 x 800W
• RAID: SHR, Basic, JBOD, RAID 0/1/5/6/10, F1
• Max Throughput: 6200 MB/s read, 4000 MB/s write

Recommendations

For optimal performance, pair with Synology 10GbE switches and use enterprise-grade SATA SSDs for caching. The RS6426XS+ is an excellent choice for businesses scaling their storage infrastructure.
