Tech Sterowniki ZS-24/30 DIN lištový napájací zdroj 24V DC 30W čierny

The Tech Sterowniki ZS-24/30 is a high-quality DIN rail power supply designed for industrial and automation applications. It delivers a stable 24V DC output with 30W of power, ensuring reliable operation for your control systems, sensors, and actuators. The compact black plastic housing is built for easy mounting on TS-35 DIN rails, making it an ideal choice for electrical cabinets and panel installations.

Advantages

This power supply offers high efficiency of over 85%, reducing energy waste and heat generation. It features comprehensive protection against overload, short circuits, and over voltage, safeguarding your connected equipment. The natural convection cooling ensures silent operation and long-term reliability without the need for fans. With a wide input voltage range of 100-240V AC and a universal frequency of 50/60 Hz, it is suitable for global use.

Suitable for

• Industrial automation systems
• PLC and control panels
• Building management systems
• Security and access control systems
• LED lighting and signage

Key specifications

• Input Voltage: 100-240V AC
• Output Voltage: 24V DC
• Output Current: 1.25A
• Output Power: 30W
• Mounting: DIN Rail (TS-35/7.5 or TS-35/15)
• Efficiency: >85%
• Ripple & Noise: <100mVp-p
• Protection: Overload, Short Circuit, Over Voltage
• Operating Temperature: -20°C to +50°C
• Cooling: Natural Convection
• Isolation Voltage: 3kV AC (Input to Output)
• Enclosure Material: Plastic
• Color: Black
• Certifications: CE, RoHS
• Input/Output Connector: Screw Terminal Block

Recommendations

For optimal performance, ensure proper ventilation around the power supply and do not exceed the rated output current. Use appropriate wire gauges for terminal connections. This unit is designed for indoor use only.
