Telegärtner 100017268 Cat.6A S/FTP patch kábel, RJ45, 7,5 m, sivý, LSZH

This Telegärtner patch cable stands out with its Cat.6A performance in a 7.5 m length, supporting 10 Gigabit Ethernet over a full 500 MHz bandwidth. The S/FTP shielding with individually foiled pairs (PiMF) and an overall braid ensures excellent protection against alien crosstalk, making it suitable for high-density data centre and office environments. The LSZH jacket reduces smoke and toxic emissions in case of fire, and the grey colour blends into most installations. Gold-plated RJ45 connectors with snagless molded boots provide reliable connections and easy handling.

Highlights

• Cat.6A (Class EA) performance up to 500 MHz
• S/FTP shielding (PiMF + overall braid) for superior noise immunity
• 10 Gigabit Ethernet support over 7.5 m
• LSZH (Low Smoke Zero Halogen) jacket for improved fire safety
• Gold-plated RJ45 connectors with snagless boots
• Grey colour for discreet installation

In daily use

This cable is ideal for connecting high-speed network devices such as servers, switches, and workstations where reliable 10G performance is required. The stranded copper conductors provide flexibility for easy routing, and the molded snagless boots protect the locking tab during installation and removal. With a length of 7.5 m, it offers extra reach for structured cabling in racks or across desks.

Full specifications

• Cable Type: Patch Cable
• Category: Cat.6A (Class EA)
• Shielding: S/FTP (PiMF)
• Length: 7.5 m
• Connector Type: RJ45 Male to RJ45 Male
• Jacket Material: LSZH
• Colour: Grey
• Conductor Material: Copper
• Conductor Type: Stranded
• Wiring Standard: T568B
• Data Transfer Rate: 10 Gbps
• Frequency Bandwidth: 500 MHz
• Connector Plating: Gold-plated contacts
• Boot Type: Molded, Snagless
• Application: Ethernet networks, Data centres, Office cabling
• Standards Compliance: ISO/IEC 11801, EN 50173, TIA/EIA-568-C.2
• Operating Temperature: -20°C to +60°C

Final note

Telegärtner is known for high-quality connectivity products, and this patch cable is built to deliver consistent performance in demanding network environments.
