UNIVIEW IPC3614LB-AF28K-A2 4MP IR bullet IP kamera, 2,8mm pevná ohnisková vzdialenosť, H.265, PoE, IP67, IK10

The UNIVIEW IPC3614LB-AF28K-A2 is a high-performance 4 Megapixel IR bullet IP camera designed for outdoor surveillance. Featuring a 1/3" Progressive Scan CMOS sensor, it delivers crisp 2560x1440 resolution at 30 fps. Equipped with a 2.8mm fixed lens (F1.6) offering a 104.4° horizontal field of view, this camera is ideal for monitoring wide areas. With built-in IR LEDs providing up to 30m night vision, digital WDR, and smart analytics (motion detection, tampering, line crossing, intrusion), it ensures reliable security day and night. The camera supports H.265/H.264/MJPEG compression, has a built-in microphone, and accepts microSD cards up to 256 GB. Its rugged IP67 and IK10 ratings make it suitable for harsh environments. Powered via 12V DC or PoE (IEEE 802.3af), it consumes max 5.5W.

Advantages

High-resolution 4MP imaging with excellent low-light performance (0.003 Lux color). Smart analytics reduce false alarms. Robust metal housing with vandal resistance (IK10) and weatherproofing (IP67). Flexible power options (DC or PoE).

Suitable for

• Outdoor perimeter surveillance
• Parking lots, warehouses, and retail stores
• Critical infrastructure monitoring

Key specifications

• Sensor: 1/3" Progressive Scan CMOS
• Resolution: 4 MP (2560x1440)
• Lens: 2.8mm fixed, F1.6
• Field of View: 104.4° (H)
• IR Distance: Up to 30m
• Video Compression: H.265, H.264, MJPEG
• Frame Rate: 30 fps @ 2560x1440
• Minimum Illumination: 0.003 Lux (color), 0 Lux with IR
• WDR: Digital WDR
• Audio: Built-in microphone
• Storage: microSD slot, up to 256 GB
• Network: 1x RJ45 10/100M Ethernet
• Power: 12V DC or PoE (802.3af), max 5.5W
• Protection: IP67, IK10
• Operating Temperature: -30°C to 60°C
• Smart Features: Motion detection, tampering, line crossing, intrusion

Recommendations

For optimal performance, use a PoE switch or injector. Ensure the microSD card is Class 10 or higher. Mount the camera at a height of 3-5 meters for best coverage.
