Vodítko výstupu fixácie Ricoh B0394102 SPEC diel fixačnej jednotky

The Fusing Exit Guide Ricoh B0394102 SPEC fuser assembly part is a replacement guide designed to direct paper through the fuser exit area of compatible Ricoh printers. It supports proper paper path alignment in the fusing section to reduce the likelihood of jams and improve feed reliability during the heat-fusing stage of printing. This component is intended for use by technicians and service centers performing scheduled maintenance or targeted repairs on Ricoh devices that require a fusing exit guide replacement.

Advantages

This fusing exit guide is manufactured to match the form and function required for the fusing assembly, providing consistent sheet guidance and dimensional stability at elevated temperatures. Designed for easy installation within the fuser module, the part helps maintain correct paper tracking and minimizes friction-related wear on sheets as they exit the fuser. Using a correct replacement guide can restore proper operation of the paper path and reduce service calls related to exit-area misfeeds.

Suitable for

• Repair and maintenance of Ricoh printers with compatible fuser assemblies
• Service center replacements during fuser module servicing
• Technicians troubleshooting recurring exit-area paper jams
• Field repairs where restoring correct paper path alignment is required

Key specifications

• Function: paper guidance through the fuser exit area
• Material characteristics: heat-resistant polymer designed for use near the fuser
• Compatibility: fits specified Ricoh fuser assemblies requiring this guide (verify device model compatibility)
• Form factor: replacement guide shaped to align with standard fuser exit geometry

How to use

Power off and unplug the printer, then allow the fuser assembly to cool before servicing. Access the fuser module following the device service manual or manufacturer's disassembly instructions. Remove the old exit guide by disengaging retaining tabs or fasteners, then install the replacement guide ensuring proper seating and alignment with adjacent feed components. Reassemble the fuser module and printer, power on the device, and run a test print to confirm correct paper passage and absence of exit-area jams.

Recommendations

Handle the part with care to avoid contamination of surfaces that contact paper. Always verify model compatibility before installation and follow the printer manufacturer’s safety and service instructions. If jams persist after replacement, inspect related feed rollers, pickup components, and sensors for wear or misalignment.
