Weidmüller 1632060000 - modrá - 4 mm² - 62 mm - 11,5 g - 100 ks

Weidmüller insulated wire end ferrule, model 1632060000, in blue colour for conductor cross-section 4 mm². This ferrule ensures reliable and secure termination of stranded wires in terminal blocks and connectors. Made of tin-plated electrolytic copper with polypropylene insulation, it offers excellent conductivity and corrosion resistance. Suitable for a wide temperature range from -40 °C to +105 °C, halogen-free and RoHS compliant. Pack of 100 pieces.

Advantages

High-quality tin-plated copper conductor ensures optimal electrical connection and long service life. Polypropylene insulation provides good mechanical protection and is halogen-free for safety. The ferrule conforms to DIN 46228 Part 4 standard, guaranteeing consistent dimensions and performance. Easy to install with standard crimping tools.

Suitable for

• Terminating stranded wires in industrial control panels
• Use in terminal blocks, connectors, and relays
• Applications requiring reliable vibration-resistant connections
• Electrical installations where halogen-free materials are required

Key specifications

• Conductor cross-section: 4 mm²
• Colour: Blue
• Total length: 20 mm
• Metal tube length: 12 mm
• Metal tube diameter: 3.0 mm
• Collar diameter: 5.8 mm
• Conductor entry diameter: 3.2 mm
• Insulation material: Polypropylene (PP)
• Conductor material: Electrolytic copper (E-Cu), tin-plated
• Operating temperature: -40 °C to +105 °C
• Flammability rating: UL 94 V-0
• Halogen-free: Yes
• RoHS compliant: Yes
• Standard: DIN 46228 Part 4
• Packaging unit: 100 pieces

Recommendations

For best results, use with a suitable crimping tool designed for insulated ferrules. Ensure the wire is stripped to the correct length before insertion. Always follow manufacturer's instructions for proper installation.
