Wittenberg Antennen LTE GPS WiFi Poly-103533 SMA adaptér - 3 m

For vehicle fleet managers and telematics installers, the Wittenberg Antennen Poly-103533 combines LTE, GPS, and WiFi in one compact antenna. The 3-meter cable with SMA male connectors simplifies routing in cars, vans, and M2M/IoT equipment.

Key specifications

• Antenna type: Multi-band (LTE, GPS, WLAN)
• LTE frequency bands: 698-960 MHz, 1710-2700 MHz (2G/3G/4G)
• GPS frequency band: 1575.42 MHz (L1)
• WLAN frequency bands: 2400-2500 MHz, 4900-5875 MHz (2.4/5 GHz)
• LTE/WLAN peak gain: 3 dBi
• GPS active gain: 28 dBi
• Connector type: SMA male (LTE/WLAN and GPS)
• Cable length: 3 m
• Cable type: RG174 low-loss coaxial
• Impedance: 50 Ohm
• VSWR: < 2.0:1
• GPS supply voltage: 3-5V DC
• GPS current consumption: < 20 mA
• Polarization: Linear (LTE/WLAN), RHCP (GPS)
• Mounting type: Adhesive
• Operating temperature: -40°C to +85°C
• Housing material: UV-resistant ABS

Why choose it

Three antennas in one housing reduce installation time and clutter. The active GPS amplifier ensures reliable positioning even in weak signal areas, while the low-loss cable preserves signal strength over the 3-meter run.

Ideal use cases

• Fleet tracking and telematics
• M2M and IoT gateways
• In-vehicle WiFi hotspots
• Asset tracking systems

Good to know

The antenna is suitable for indoor and outdoor use with its UV-resistant housing. It requires a 3-5V DC supply for the GPS amplifier, typically provided by the connected device.
