ACO FAM-P-ZSACC revízna klapka pre sadrokartón s číselným zámkom 600x600 mm

The ACO FAM-P-ZSACC plaster panel with combination lock is a high-quality inspection panel designed for flush-mounted installation in drywall and plasterboard walls and ceilings. It provides easy access to hidden installations while maintaining a clean, paintable surface.

Advantages

This panel features a robust aluminum frame and a plasterboard door that can be painted to match the surrounding wall. The integrated combination lock ensures secure access, while the push-to-open mechanism allows for convenient operation after unlocking. The door is removable and reversible, offering flexibility during installation.

Suitable for

• Drywall and plasterboard walls and ceilings
• Access to plumbing, electrical, or HVAC systems
• Commercial and residential buildings

Key specifications

• Product Type: Inspection Panel
• Panel Material: Plasterboard (GK)
• Frame Material: Aluminum
• Lock Type: Combination Lock
• External Dimensions (W x H): 600 x 600 mm
• Installation Opening Dimensions (W x H): 605 x 605 mm
• Panel Thickness: 12.5 mm
• Frame Depth: 25 mm
• Application: Drywall, Plasterboard Walls & Ceilings
• Installation Method: Flush-mounted
• Opening Mechanism: Hinged, Push-to-open (after unlocking)
• Number of Locks: 1
• Finish: White, Paintable
• Door Design: Removable/Reversible
• Max Opening Angle: 90°
• Mounting Orientation: Universal (Vertical/Horizontal)
• Corrosion Resistance: Yes (Aluminum frame)

Recommendations

For best results, ensure the installation opening is precisely cut to 605 x 605 mm. The panel can be painted with standard wall paint after installation.
