ALLNET STT-RJ45 RJ45 konektor samec nezatienený Cat.6 na montáž v teréne pre KEFA Phoenix

The ALLNET STT-RJ45 is a high-quality, unshielded RJ45 plug designed for field termination, compatible with KEFA Phoenix systems. This connector supports Cat.6 performance and is backward compatible with Cat.5e, making it ideal for industrial Ethernet and network infrastructure applications. Its tool-less IDC termination allows for quick and reliable installation on solid or stranded twisted pair cables (AWG 24-22). The plug features gold-plated contacts for optimal signal integrity and is reusable for cost-effective deployments.

Advantages

Tool-less installation saves time and reduces the need for specialized tools. The unshielded design is suitable for environments where electromagnetic interference is minimal, offering a cost-effective solution. Gold-plated contacts ensure reliable connectivity and long-term performance. Reusability allows for easy reconfiguration and maintenance.

Suitable for

• Industrial Ethernet networks
• Data center cabling
• Network infrastructure installations
• KEFA Phoenix compatible systems
• Field-terminated patch cables

Key specifications

• Connector Type: RJ45 Plug
• Shielding: Unshielded (UTP)
• Category: Cat.6 (backward compatible with Cat.5e)
• Termination: Tool-less / IDC
• Contacts: 8P8C, Phosphor Bronze, Gold-plated (50µ")
• Housing: High-grade Plastic (PC/ABS), Grey
• Wire Gauge: AWG 24-22 (Solid and Stranded)
• Standards: TIA/EIA-568A/B
• Operating Temperature: -40°C to +70°C
• Humidity: 10% to 90% non-condensing
• Max Data Rate: 10 Gigabit Ethernet (over shorter distances)

Recommendations

For optimal performance, use with Cat.6 or higher cabling and ensure proper termination according to TIA/EIA-568 standards. Suitable for both solid and stranded conductors.
