APC Smart-UPS X 2000 VA 1800 W line-interactive UPS rack/tower 2U

The APC Smart-UPS X SMX3000RMHV2UNCR is a high-performance line-interactive UPS designed for critical server, network, and telecommunications equipment. With 2000 VA / 1800 W output power, it provides reliable battery backup and surge protection in a compact 2U rack/tower form factor. Ideal for small to medium businesses, this UPS ensures clean sine wave output and extended runtime capability with optional external battery packs.

Advantages

Reliable line-interactive topology with automatic voltage regulation (AVR) corrects under- and over-voltage conditions without switching to battery, extending battery life. The multi-function LCD display provides real-time UPS status, load, and battery information. SmartSlot and USB interfaces allow for remote monitoring and management via APC PowerChute software. Emergency Power Off (EPO) capability enhances safety in data center environments.

Suitable for

• Servers and storage systems
• Network switches and routers
• Telecommunications equipment
• Small to medium business IT environments

Key specifications

• Output Power Capacity: 2000 VA / 1800 W
• Nominal Output Voltage: 230 V
• Output Connections: 8 x IEC 320 C13, 2 x IEC Jumpers
• Input Connection: IEC-320 C14
• UPS Technology: Line-Interactive
• Waveform Type: Sine wave
• Form Factor: Rack/Tower (2U)
• Battery Type: Maintenance-free sealed Lead-Acid
• Typical Recharge Time: 3 hours
• Runtime (Full Load): 4.5 minutes (1800W)
• Runtime (Half Load): 17.5 minutes (900W)
• Interface Ports: SmartSlot, USB
• Control Panel: Multi-function LCD
• Extended Runtime Capability: Yes (with external battery packs)
• Emergency Power Off (EPO): Yes (optional)
• Operating Temperature Range: 0 - 40 °C
• Input Voltage Range (Main Operations): 151 - 302 V

Recommendations

For maximum uptime, pair this UPS with APC external battery packs (e.g., SMX120BP) to extend runtime during extended outages. Use the SmartSlot for a network management card to enable remote shutdown and monitoring.
