ATTE IP-5-11-E 5-port Fast Ethernet PoE switch so 4 PoE portami, 78W rozpočet, Extend Mode a izolácia portov

The ATTE IP-5-11-E is a 5-port Fast Ethernet switch engineered specifically for powering and connecting up to four IP cameras. Unlike generic unmanaged switches, this model integrates a generous 78W PoE budget, Extend Mode for long-distance deployment, and port isolation to enhance security and performance in surveillance installations.

Highlights

• 5× 10/100 Mbps RJ45 ports (4 PoE + 1 uplink)
• IEEE 802.3af/at PoE with up to 30W per port
• Total PoE power budget: 78W
• Extend Mode: data and power up to 250m at 10 Mbps
• Port isolation (VLAN) to secure camera traffic
• Metal housing, desktop or wall-mountable

In daily use

Set up a reliable surveillance network without the need for individual power adapters. The switch automatically detects PoE devices and supplies the required power, simplifying installation. When cameras are located far from the switch, enable Extend Mode to push the reach to 250 meters, ideal for perimeter monitoring. Port isolation prevents broadcast storms and unauthorized access between cameras, while surge protection safeguards your equipment.

Full specifications

• Total Ethernet ports: 5
• PoE ports: 4× 10/100 Mbps RJ45
• Uplink ports: 1× 10/100 Mbps RJ45
• PoE standard: IEEE 802.3af/at
• Total PoE power budget: 78 W
• Max power per PoE port: 30 W
• Ethernet speed: Fast Ethernet (10/100 Mbps)
• Switching capacity: 1 Gbps
• Forwarding rate: 0.74 Mpps
• MAC address table: 1K
• Jumbo frame support: 1536 Bytes
• Management type: Unmanaged
• Power supply: External DC 52V / 1.5A
• Operating temperature: -10°C to 40°C
• Housing material: Metal
• Special features: Extend Mode (250m @ 10Mbps), Port Isolation (VLAN), Surge Protection
• Mounting: Desktop, wall-mountable

Final note

This switch provides a cost-effective and robust solution for IP camera systems, offering high PoE capacity and advanced features typically found in more expensive managed switches. Its plug-and-play design ensures quick deployment, while the metal casing ensures durability in demanding environments.
