Avaya Ethernet Routing Switch 4524GT-PWR - Managed Layer 2/3 Gigabit PoE switch - 24 portov 10/100/1000 + 4 Shared SFP - Desktop/Rackmount - PoE+

The Avaya Ethernet Routing Switch 4524GT-PWR is a high-performance managed Layer 2/3 Gigabit Ethernet switch designed for enterprise networks. It provides 24 10/100/1000Base-T PoE+ ports and 4 shared SFP uplink ports, delivering reliable connectivity and power to network devices such as IP phones, wireless access points, and security cameras. With a PoE budget of 370 W, it supports IEEE 802.3af/at standards, making it ideal for powering demanding devices. The switch offers advanced features including VLAN support, QoS, security protocols, and stacking capability for up to 8 units, ensuring scalability and robust network management.

Advantages

This switch combines high port density with Power over Ethernet Plus (PoE+) to simplify deployment and reduce cabling costs. Its managed capabilities provide granular control over network traffic, while the stacking feature allows for easy expansion. The 96 Gbps switching capacity and 71.4 Mpps forwarding rate ensure wire-speed performance for bandwidth-intensive applications.

Suitable for

• Enterprise edge and access layer deployments
• Networks requiring PoE+ for IP phones, cameras, and WAPs
• Small to medium-sized businesses needing a scalable, managed switch

Key specifications

• Device Type: Managed Layer 2/3 Switch
• Enclosure: Desktop, Rack-mountable 1U
• Ports: 24 x 10/100/1000Base-T (PoE+) + 4 x Shared SFP
• PoE Budget: 370 W
• Switching Capacity: 96 Gbps
• Forwarding Rate: 71.4 Mpps
• MAC Address Table: 16K entries
• Jumbo Frame Support: Up to 9 KB
• Routing Protocols: RIP-1, RIP-2, Static IP Routing
• Management: SNMP, RMON, Telnet, HTTP, HTTPS, SSH, CLI
• VLAN Support: IEEE 802.1Q, GVRP
• QoS: IEEE 802.1p, DiffServ, WRR
• Security: 802.1X, RADIUS, TACACS+, ACLs, DHCP Snooping, DAI
• Stackable: Up to 8 units
• Power Supply: Internal AC 100-240 V, 50/60 Hz

Recommendations

For optimal performance, use this switch with Avaya IP phones and wireless access points. Ensure adequate ventilation when rack-mounting. The switch supports both desktop and rackmount installations, providing flexibility for various environments.
