BCS BASIC BCS-B-SEIP(2.0) PoE adaptér 30W Gigabit

The BCS BASIC BCS-B-SEIP(2.0) is a high-performance Power over Ethernet (PoE) adapter designed to deliver reliable power and data connectivity for PoE-enabled devices such as IP cameras, wireless access points, and VoIP phones. Compliant with IEEE 802.3af/at standards, this adapter provides up to 30W of power over a single Ethernet cable, simplifying installation by eliminating the need for separate power outlets.

Advantages

This PoE adapter offers a cost-effective and efficient solution for powering network devices. With its compact desktop/wall-mountable design, it integrates seamlessly into any environment. The adapter features robust protection against overload, short circuit, and overvoltage, ensuring safe operation. LED indicators for power and PoE status provide at-a-glance monitoring.

Suitable for

• IP security cameras (CCTV)
• Wireless access points (WAP)
• VoIP phones
• Network switches and other PoE-compatible devices

Key specifications

• PoE Standard: IEEE 802.3af/at (PoE/PoE+)
• Max Output Power: 30 W
• Data Transfer Rate: 10/100/1000 Mbps (Gigabit Ethernet)
• Input Voltage: AC 100-240V, 50/60 Hz
• Output Voltage: DC 48-56V
• Number of Data In Ports: 1 x RJ45
• Number of PoE Out Ports: 1 x RJ45
• LED Indicators: Power, PoE Status
• Protection Features: Overload, Short Circuit, Overvoltage
• Operating Temperature: -10°C to +45°C
• Storage Temperature: -20°C to +70°C
• Operating Humidity: 5% to 90% RH (non-condensing)
• Housing Material: Plastic
• Power Consumption (No Load): < 0.5 W
• Mounting Type: Desktop / Wall-mountable
• Certifications: CE, FCC

Recommendations

For optimal performance, use with Cat5e or higher Ethernet cables. Ensure the connected device is PoE-compatible and does not exceed the maximum power output. This adapter is ideal for small to medium-sized network installations requiring reliable power delivery.
