BCS BCS-L-AT3-G napájací zdroj 12V 3A 36W CCTV

The BCS BCS-L-AT3-G is a high-quality power adapter designed for reliable and efficient power delivery to CCTV cameras, DVRs, NVRs, LED strips, and other compatible devices. With a robust 12V DC output at 3A (36W), this adapter ensures stable performance for your security and lighting systems. Featuring a compact ABS plastic housing and a 1.2-meter output cable with a 5.5 x 2.1 mm barrel plug (center positive), it is easy to install and use. The adapter meets Level VI efficiency standards and includes overload, short circuit, and overvoltage protection for safe operation.

Advantages

This power adapter offers a reliable power solution with multiple protection features, ensuring the safety of your connected devices. Its universal input voltage range (100-240V AC) makes it suitable for use worldwide, while the integrated Europlug (Type C) simplifies connection to mains outlets. The high efficiency and low ripple and noise (<100mV) contribute to clean power delivery, extending the lifespan of your equipment.

Suitable for

• CCTV cameras and surveillance systems
• DVRs and NVRs
• LED strip lights
• Other devices requiring 12V DC power at up to 3A

Key specifications

• Input: 100-240V AC, 50/60 Hz
• Output: 12V DC, 3A, 36W
• DC Connector: 5.5 x 2.1 mm barrel plug, center positive
• Output Cable Length: 1.2 meters
• Protection: Overload, Short Circuit, Overvoltage
• Efficiency: Level VI
• Operating Temperature: -10°C to 50°C
• Housing Material: ABS Plastic
• Color: Black
• Certifications: CE, RoHS
• MTBF: 50,000 hours

Recommendations

For optimal performance, ensure that the total current draw of connected devices does not exceed 3A. This adapter is not suitable for outdoor use unless protected from moisture. Always verify polarity before connection.
