Busch-Jaeger IP spínací aktor H8304-03 (2TMA130160H0061)

The IP switching actuator H8304-03 from Busch-Jaeger offers two independent switching channels with 16 A capacity each, controlled via KNX IP over Ethernet. It integrates seamlessly into KNX installations and provides manual operation, status display, and advanced logic functions.

Advantages

This actuator combines reliable switching performance with flexible IP connectivity, enabling remote control and monitoring through standard network infrastructure. Its compact 4 TE DIN rail design saves space in distribution boards.

Suitable for

• Lighting control in residential and commercial buildings
• Switching of resistive loads up to 2300 W per channel
• LED lighting loads up to 400 W per channel
• Integration into KNX systems with IP backbone

Key specifications

• 2 channels, 16 A each, 230 V AC
• KNX IP communication via RJ45 Ethernet
• 24 V DC power supply (PoE or external)
• DIN rail mounting, 4 TE width
• Manual operation and status display
• Scene control, time functions, logic functions

Recommendations

For reliable switching in KNX installations with IP connectivity, the H8304-03 offers a robust solution with easy commissioning and flexible control options.
